答：要知道37kw羅茨風機風量多大，需要查詢公司的產品樣冊!37KW三葉羅茨風機能夠搭配許多風量主要參數，羅茨風機的規格也是有多種多樣，小編RZ系列產品為例子，為我們例舉一下37KW羅茨風機能夠配對什么型號規格主要參數。通過產品樣冊查詢得知：適配37kw電機的型號規格有RZ150、RZ175、RZ200、RZ250、RZ300、RZ350.備注名稱：這里舉個例子僅以單級羅茨鼓風機為例子。

37千瓦羅茨風機參數

　　RZ150s所適配的風量有：29.03、26.27、28.96、24.55、26.15、24.48、26.08、21.83、22.95、24.32、20.87、21.74、22.82、24.27(單位：立方/min)

　　所涵蓋的壓力范疇有：34.3kpa、39.2kpa、44.1kpa、49kpa、53.9kpa、58.8kpa

　　RZ-SS175所適配的風量有：39.6、37.84、39.31、35.35、37.43、32.55、33.86、35.17、37.15、32.33、33.64、36.96、26.34、28.05、24.05、26.15、27.84、23.95、25.95(單位：立方/min)

　　所涵蓋的壓力范疇有：24.5kpa、29.4kpa、34.3kpa、39.2kpa、44.1kpa、49kpa、53.9kpa、58.8kpa

　　RZ-MJ200所適配的風量有：54.43、58.61、54.73、58.41、48.42、51.51、41.43、45.01、37.07、41.11、33.03、36.75、28.55、32.75、28.24(單位：立方/min)

　　所涵蓋的壓力范疇有：14.7kpa、19.6kpa、24.5kpa、29.4kpa、34.3kpa、39.2kpa、44.1kpa、49kpa

　　RZ-250n所適配的風量有：97.1、74.7、80.0、90.0、74.3、79.6、62.9(單位：立方/min)

　　所涵蓋的壓力范疇有：9.8kpa、14.7kpa、19.6kpa、24.5kpa

　　RZ-SW-V300所適配的風量有：105.8、112.9、88.9(單位：立方/min)

　　所涵蓋的壓力范疇有：9.8kpa、19.6kpa

　　RZ-SY-350所適配的風量有：165.7、181.3(單位：立方/min)

　　所涵蓋的壓力范疇有：9.8kpa

　　以上便是我公司生產的銷售37KW的羅茨風機的風量風壓參數，以上參數僅供各位客戶選購37KW羅茨風機時參考使用!

　　To know the air volume of 37KW roots blower, you need to query the company's product sample book! 37KW three blade roots blower can be matched with many main parameters of air volume, and the specifications of Roots blower are also diverse. Taking small series RZ products as an example, let's give us an example of the main parameters of the model and specification that 37KW roots blower can be matched with. It is known from the product sample book that the models and specifications of 37KW motors are rz150, rz175, rz200, rz250, rz300 and rz350 Note name: for example, only single-stage roots blower is taken as an example.

　　The air volume of rz150s is 29.03, 26.27, 28.96, 24.55, 26.15, 24.48, 26.08, 21.83, 22.95, 24.32, 20.87, 21.74, 22.82, 24.27 (unit: m3 /min)

　　The pressure categories covered are: 34.3kpa, 39.2kpa, 44.1kpa, 49kpa, 53.9kpa, 58.8kpa

　　The air volume for rz-ss175 is 39.6, 37.84, 39.31, 35.35, 37.43, 32.55, 33.86, 35.17, 37.15, 32.33, 33.64, 36.96, 26.34, 28.05, 24.05, 26.15, 27.84, 23.95, 25.95 (unit: m3 /min)

　　The pressure categories covered are: 24.5kpa, 29.4kpa, 34.3kpa, 39.2kpa, 44.1kpa, 49kpa, 53.9kpa, 58.8kpa

　　The air volume of rz-mj200 is 54.43, 58.61, 54.73, 58.41, 48.42, 51.51, 41.43, 45.01, 37.07, 41.11, 33.03, 36.75, 28.55, 32.75, 28.24 (unit: m3 /min)

　　The pressure categories covered are: 14.7kpa, 19.6kpa, 24.5kpa, 29.4kpa, 34.3kpa, 39.2kpa, 44.1kpa, 49kpa

　　The air volume of rz-250n is 97.1, 74.7, 80.0, 90.0, 74.3, 79.6, 62.9 (unit: m3 /min)

　　The pressure categories covered are: 9.8kpa, 14.7kpa, 19.6kpa, 24.5kpa

　　The air volume of rz-sw-v300 is 105.8, 112.9 and 88.9 (unit: m3 /min)

　　The pressure categories covered are: 9.8kpa, 19.6kpa

　　The air volume of rz-sy-350 is 165.7 and 181.3 (unit: m3 /min)

　　Pressure range covered: 9.8kpa

　　The above are the air volume and pressure parameters of 37KW roots blower produced and sold by our company. The above parameters are only for your reference when purchasing 37KW roots blower!
